Bulkhead Fittings and tubing barbs

Site Category drop down menu for site selection pages.

Product drop down menu for going directly to product pages.

BulkheadF-K03

Bulkhead Kit as
 shown

requires additional Elbow Hose Barb

This style requires additional Elbow Hose Barb

BULKHEAD FITTINGS
The key to setting up a Central Filter System is being able to overflow water from your existing tanks into a central sump area. To do this the first step is to install Bulkhead Fittings in each tank at the height you wish to maintain water level. For smaller tanks or those with a slow turnover rate use 1/2” B-Fittings. The 3 listed below with the “K” suffix are supplied as complete tank fitting kits which include an Intake Screen and elbow (90deg.) Hose Barb Fitting. Material is ABS plastic unless specified otherwise. ABS slip fittings can be glued using conventional PVC cement or ABS cement. All bulkhead fittings include a nut and rubber washer for securing a water-tight seal on any glass or acrylic aquarium or plastic tank wall. Separate parts are also available. For large high volume applications (large Aquariums) we suggest using the higher grade PP style Fittings.
We also carry Intake Sponges to guard against small fry passage, as well as clear PVC Flexible Tubing and a large selection of various hose barbs / tubing fittings to connect to PVC drain lines.

Item #


Description

Required
 hole size

Price each

Price each
@ (12)

1/2” Bulkhead Fittings

BF1/2K

BF05K_100p

1/2” Bulkhead kit
slip x slip
w/ slip intake strainer & elbow barb

1 1/8”

$5.75

$5.25

BF1/2KST



1/2” Bulkhead kit
slip x thread
w/ slip intake strainer & threaded elbow hose barb

1 1/16” to 1 1/8”

$5.95

$4.95

BF1/2SB

BF05SK-100P

1/2 Bulkhead fitting with integrated straight 1/2” hose barb

1 1/8”

$5.85

$5.35

BF1/2

BF05SXS_100p

1/2” Bulkhead Fitting
slip inlet x slip outlet

1 1/8”

SALE
$2.50

reg. $4.00

$3.89

BF1/2CLR



1/2” Bulkhead Fitting,
 clear plastic
slip x slip

1 1/8”

$4.50

$3.89

BF1/2THD1

BF05THD_100p

1/2” Bulkhead only
threaded intake x slip outlet

1 1/16”
 to 1 1/8”

$5.25

$5.25

BF1/2THD1-O

BF05SXS_100p1

1/2” Bulkhead only
slip intake x
threaded outlet

1 1/16”
 to 1 1/8”

$4.95

$4.45

BF1/2THD2

BF05THD_100p

1/2” Bulkhead only
threaded inlet x threaded outlet

1 1/18”

$4.95

$4.45

3/4” Bulkhead Fittings

Item #


Description

Required
 hole size

Price each

Price each
@ (12)

BF3/4K

BF075K_100p

3/4” Bulkhead Kit
slip x slip
w/slip Intake Strainer & elbow barb

1 1/2”

$5.90

$5.45

BF3/4K-CB

same as above in translucent blue

3/4” Bulkhead Kit
clear  blue
slip x slip
w/slip Intake Strainer & elbow barb

1 1/2”

$5.90

$5.45

BF3/4KST



3/4” Bulkhead kit
slip x thread
w/ slip intake strainer & threaded elbow hose barb

1 1/2”

$6.25

$5.75

BF3/4SB

BF075KS-100P

3/4” Bulkhead Fitting with integrated 3/4” hose barb

1 1/2”

$5.95

$5.45

BF3/4

BF075SXS_100p

3/4” Bulkhead only,
slip inlet x slip outlet

1 1/2”

$4.25

$4.00













BF3/4THD1

BF075THD_100p

3/4” Bulkhead fitting only
threaded intake side x slip outlet

1 1/2”

$5.00

$4.50

BF3/4THD1H



3/4” Bulkhead fitting - heavy wall ABS
thread x slip

1 5/8”

$6.00

$5.50

BF3/4THD1-O

BF075SXS_100p1

3/4” Bulkhead only
slip intake x
threaded outlet

1 3/8” to
 1 1/2”

$5.00

$4.50

BF3/4THD2

BF075THD_100p

3/4” Bulkhead fitting only
threaded intake x threaded outlet

1 3/8” to
 1 1/2”

$5.00

$4.50

BF3/4THD2-CLR

same as above in clear plastic

3/4” Bulkhead fitting
clear
threaded intake x threaded outlet

1 3/8” to
 1 1/2”

$5.50

$5.20

1” Bulkhead Fittings

Item #


Description

Required
 hole size

Price each

Price each
@ (12)

BF1K

BF1K_100p

1” Bulkhead Kit, slip x slip
 w/ slip Intake Strainer & slip elbow barb

1 3/4”

$6.25

$5.75

BF1KB

same as above in translucent blue

1” Bulkhead Kit, clear blue
slip x slip
 w/ slip Intake Strainer & slip elbow barb

1 3/4”

$6.25

$6.00

BF1KST



1” Bulkhead kit
slip x thread
w/ slip intake strainer & threaded elbow hose barb

1 3/4”

$6.45

$5.95

BF1SB

BF1KS-100p

1” Bulkhead fitting with integrated straight 1” hose barb

1 3/4”

$6.05

$5.75

BF1

BF1SXS_100p

1” Bulkhead only
slip inlet x slip outlet

1 3/4”

$4.35

$4.10

BF1THD1

BF1THD_100p

1” Bulkhead only
threaded inlet x slip outlet

1 3/4”

$6.50

$6.05

BF1THD1-O

BF1SXS_100p

1” Bulkhead only
slip inlet x threaded outlet

1 3/4”

$6.50

$6.05

BF1THD2

BF1THD_100p

1” Bulkhead only
threaded inlet x threaded outlet

1 3/4”

$5.95

$5.05

1 1/4” Bulkhead Fitting

BF125PP

BF125PP-100

 1 1/4” Heavy  Polypropylene Bulkhead thd x thd

2 1/4”

$14.00



1 1/2” Bulkhead Fittings

Item #


Description

Required
 hole size

Price each

Price each
@ (12)

BF1.5

BF15_100p1

1 1/2” Bulkhead only
slip inlet x slip outlet

2 3/8” to
2 1/2”

$5.50

$5.00

BF1.5THD1

BF15THD_100p

1 1/2” Bulkhead only
threaded inlet x slip outlet

2 3/8” to
 2 1/2”

$5.50

$5.00

BF1.5THD1-O

BF15_100p1

1 1/2” Bulkhead only
slip inlet x threaded outlet

2 3/8” to
 2 1/2”

$5.50

$5.00

BF1.5THD2

BF15THD_100p

1 1/2” Bulkhead fitting only
threaded inlet x threaded outlet

2 3/8” to
 2 1/2”

$5.50

$5.00

BF1.5TTPP

BF15PP-100p

1 1/2” Heavy Duty
Bulkhead Fitting Polypropylene
thd in x thd out

3”

$15.00



2” Bulkhead Fittings

Item #


Description

Required
 hole size

Price each

Price each
@ (12)

BF2

BF2SXS_100p

2” Bulkhead fitting only
slip inlet x slip outlet

2 7/8” to
3 1/8”

$5.75

$5.25

BF2THD1

BF2TXT_100p

2” Bulkhead only
threaded inlet x slip outlet

3” to 3 1/4”

$6.50

$6.25

BF2THD1-O

BF2SXS_100p

2” Bulkhead fitting
slip inlet x threaded outlet

2 7/8” to
3 1/8”

$5.75

$5.25

BF2THD2

BF2TXT_100p

2” Bulkhead fitting only
threaded inlet x threaded outlet

2 7/8” to
 3 1/8”

$5.75

$5.25

BF2TTPP

BF2PP-100p

2” Heavy Duty
Bulkhead Fitting Polypropylene
thd in x thd out w/ plastic pressure washer for nut side

3”

$15.00



BF2TTPPHD

BF2PPHD-100p

2” Extra Heavy Duty
Bulkhead Fitting Polypropylene
thd in x thd out w/ plastic pressure washer for nut side
elbow siphon tube for bottom draining

3 1/4”

$21.95



3” Bulkhead Fittings

BF3HDTHD2

BF3THD2_100p

 Heavy Duty 3” Bulkhead, Threaded inlet and outlet
useful for connecting large sumps or intakes on large pumps

4 1/2”

$34.50



4” Bulkhead Fittings

BF4TTPP

BF4PPa-100p

 Heavy Duty 4” Bulkhead, Threaded inlet and outlet
useful for connecting large sumps or intakes on large pumps

5 5/8” - 6”

$79.50



Miniature Bulkhead hose barbs
use for small aquariums or holding tanks such as our HTN
Includes hex nut & flat rubber washer for proper seal.
Washer to be installed on flange side of fitting.
Also available without washer and nut for direct threaded panel connection
 or where rubber sealing gasket is not needed

Item #


Description

 required
hole size

price each

5/16” (8mm) hole size required:

PHBBF0532MIC

PHBBF0532MIC-100p

airline barb bulkhead

5/16”
(8 mm)

$1.70

PHBBF0532X0532MIC

PHBBF0532X0532MIC-100p

airline x airline
barb bulkhead

5/16”
(8 mm)

$1.94

PHBBFL0532MIC

PHBBFL0532MIC-100p

airline elbow barb bulkhead

5/16”
(8 mm)

$2.03

PHBBFL0532X0532MIC

PHBBFL0532X0532MIC-100p

airline x airline elbow barb bulkhead

5/16”
(8 mm)

$2.27

PHBBF014MIC

PHBBF014MIC-100p

1/4” barb bulkhead

5/16”
(8 mm)

$1.78

13/32” (10mm) hole size required:

PHBBF0532MC

PHBBF0532MC-100p

airline barb bulkhead

13/32”
(10 mm)

$1.82

PHBBFL0532MC

PHBBFL0532MC-100p

airline elbow barb bulkhead

13/32”
(10 mm)

$2.18

PHBBF014MC

PHBBF014MC-100p

1/4” barb bulkhead

13/32”
(10 mm)

$1.94

PHBBFL014MC

PHBBFL014MC-100p

1/4” elbow barb bulkhead

13/32”
(10 mm)

$2.27

1/2” (13mm) hole size required:

PHBBF0532C

PHBBF0532C-100p

airline barb bulkhead

1/2”

$1.49

PHBBFL0532C

PHBBFL0532C-100p

airline elbow barb bulkhead

1/2”

$2.39

PHBBF-1/4

PHBBF-025-100p

barb bulkhead 1/4” hose

1/2”

$1.79

PHBBF014X014C

PHBBF014X014C-100p

1/4” barb x 1/4” barb bulkhead

1/2”

$1.88

PHBBFLR014X0532C



1/4” barb x airline elbow barb bulkhead

1/2”



PHBBFL014C

PHBBFL014C-100p

1/4” elbow barb

1/2”

$1.98

PHBBF-3/8

PHBBF-0375-100p

barb bulkhead
3/8” hose

1/2”

$1.98

PHBBF038X038C

PHBBF038X038C-100p

3/8” barb x 3/8” barb bulkhead

1/2”

$1.97

PHBBF-1/2

PHBBF-050-100p

barb bulkhead
1/2” hose

1/2”

$1.82

PHBX-RCG-100pHose Barb tank/pipe adapters: A cost effective solution for use in place of a bulkhead fitting on plastic tanks or excellent for drain connections to PVC pipe. Saves time and cost running multiple drain hose connections as common in Central Systems. Can also be used on low pressure supply lines. Available for flexible tubing sizes 1/2” ID through 3/4” ID

Examples of various uses:

PHBXP-tank1-100pPHBXP-tank-100p1PHBXP-3pipe100pPHBXP-3pipeside100pPHBXP-3pipetopside100p

#10 grommet size barbs are the smallest and will fit 1” Schedule 40 PVC pipe

PHBXP10X14MM

PHBXP10X14MH-100p

14mm hose barb x
#10 grommet insert

requires #10 grommet

$0.54

PHBXP10X0916H

PHBXP10X0916H-100p

9/16” (15mm)
hose barb x
#10 grommet insert

requires #10
grommet

$0.58

#13 grommet size barbs are best for pipe sizes 1 1/4” PVC and larger

PHBXP13X012H

PHBXP13X012H-100p

1/2” hose barb x #13 grommet insert

requires #13 grommet

$0.52

PHBXP13X14MH

PHBXP13X0916H-100p

14 mm hose barb x #13 grommet insert

requires #13 grommet

$0.54

PHBXP13X0196H

PHBXP13X15MH-100p

9/16 hose barb x #13 grommet insert

requires #13 grommet

$0.56

#16 grommet size barbs are best for pipe sizes 1 1/4” PVC and larger

PHBXP16X058H

PHBXP16X058Ha-100p

5/8 hose barb x #16 grommet insert

requires #16 grommet

$0.90

#19 grommet size barbs are best for pipe sizes 1 1/2” PVC and larger

PHBXP19X034H

PHBXP19X034H-100p

3/4 hose barb x #19 grommet insert

requires #19 grommet

$1.12

PHBXP19X1H

PHBXP19X1H-V100p

1” hose barb x
#19 grommet insert

requires #19 grommet

$1.43

RCG13-19-150pGROMMETS: for above insert barbs

RCG10

RCG10-100p

#10 grommet
curved grommet flange for better fit on 1” pipe can also be used on flat surfaces

35/64” hole
(14 mm)

$0.35

RCG10-DB

RCG10-DB-100p

Drill bit for #10 grommet
special self centering stub bit with depth stop



$29.00

RCG13



#13 grommet

~ 5/8” hole

$0.35

RCG16



#16 grommet

~ 3/4” hole

$0.47

RCG19



#19 grommet

~ 7/8” hole

$0.56

Bulkhead Parts - Intake Screens, Elbow Hose Barbs, Straight Hose Barbs

Item #


Description

Price

Price at Qty

IS1/2S

IS05S_100p

1/2” Slip Intake Screen

$1.02

$0.79
@ 25

IS1/2THD

IS05T_100p

1/2” Threaded Intake Screen

$2.08

$1.69
@ 25











IS3/4S

IS075S_100p

3/4” Slip Intake Screen

$1.15

$0.92
@ 25

IS3/4THD

IS075T_100p

3/4” Threaded Intake Screen

$2.20

$1.79
@ 25











IS1S

IS1S_100p

1” Slip Intake Screen

$1.20

$0.94
@ 25

IS1THD

IS1T_100p

1” Threaded Intake Screen

$2.89

$2.40
@ 25

IS1DBLK

IS1D-bk2-100p

1” bulkhead clip on BLACK disk screen
sits flush on flange of bulkhead fitting non-protruding makes catching fish easier
will somewhat reduce flow capacity of bulkhead - must be glued in place with ABS or PVC cement or Silicone

$1.48

$1.18
@ 25

IS1DBLU

IS1D-blue-100p

1” bulkhead clip on BLUE disk screen
sits flush on flange of bulkhead fitting non-protruding makes catching fish easier
will somewhat reduce flow capacity of bulkhead -  must be glued in place with ABS or PVC cement or Silicone

$1.48

$1.18 @ 25

IS1.5THD

IS15T_100p

1 1/2” Threaded Intake Screen

$4.25

$3.50
@ 25

IS2THD

IS2T_100p

2” Threaded Intake Screen

$6.95

$5.95
@ 25

IS2THDF

IS3-002_100p

2” Female Threaded Intake Screen, large surface area for higher volume flow rates without clogging

$14.95



IS3THDF

IS3-002_100p

3” Female Threaded Intake Screen, large surface area for higher volume flow rates without clogging

$27.95



BE1/2

BE05S_100p

1/2” Slip Bulkhead Elbow

1.50

1.17

BE3/4

BE075S_100p

3/4” Slip Bulkhead Elbow Hose Barb

1.75

1.37

BE1

BE1S_100p

1” Slip Bulkhead Elbow Hose Barb

2.10

1.65

PHBS1/2x1/2

PHBS05X05_100p

1/2” Slip Bulkhead Straight Hose Barb

$1.29



PHBS3/4x3/4

PHBS075X075_100p1

3/4” Slip Bulkhead Straight Hose Barb

$1.52



PHBS1x1

PHBS1X1_100p

1” Slip Bulkhead Straight Hose Barb

$1.63



PHBE1/2x1/2

PHBE05_100p

1/2” Threaded Elbow Hose Barb
1/2” hose x 1/2 MNPT

$0.89



PHBE.75x.50

PHBE075_100p

Threaded Elbow Hose Barb 3/4 x 1/2
3/4” Hose x 1/2” MNPT

$1.05



PHBE.75x.75

PHBE075_100p1

3/4” Threaded Elbow Hose Barb
3/4” hose x 3/4 MNPT

$0.93



PHBE1x1

PHBE1_100p

1” Threaded Elbow Hose Barb
 1” hose x 1 MNPT

$1.19



PHBE150X150



1 1/2” Threaded Elbow Hose Barb
1 1/2” ID Hose x 1 1/2 MNPT (color is black)

$7.50



PHBE2X2



2” Threaded Elbow Hose Barb
2” ID Hose x 2” MNPT
(color is yellow or black)

$9.95



PHB05X05

PHB05_100p

Straight Hose Barb, 1/2 hose x1/2 MNPT

$0.80



PHB075X075

PHB075_100p

Straight Hose Barb, 3/4 hose x 3/4 MNPT

$0.89



PHB1X1

PHB1_100p

Straight Hose Barb, 1” hose x 1 MNPT

$1.45























PHB1.25x1.25

PHB125_100p

Straight Hose Barb
1 1/4” Hose x 1 1/4 NPT male thread

$1.50



PHB1.5x1.5

PHB15_100p

Straight Hose Barb
1 1/2 Hose x 1 1/2 NPT male thread

$1.69



PHB2X2



Straight Hose Barb
2” ID Hose x 2” MNPT

$2.30



BFG-1/2



Bulkhead Fitting Gasket for 1/2” BF

$0.43



BFG-3/4



Bulkhead Fitting Gasket for 3/4” BF

$0.49



BFG-1



Bulkhead Fitting Gasket for 1” BF

$0.54



FILL VALVES:
Water Fill Valves are used to regulate flow back to the individual tanks from a centralized water pump. Available in 1/4”, 3/4”, and 1” pipe sizes. All valves have a male NPT thread at the inlet side and output the water at a 90 degree angle or straight inline (as PBV1/2X1/4NPT), with a spigot style outlet (no fitting). Uses a lever style adjustment with quarter or half turn actuation. See other valves barb x barb style here

Item #


Description

Price

Price @ 50

PBV1/2X1/4

PBV12X14NPTe1-100p

1/4”NPT Fill Valve
1/4 MNPT thread x
7/16” - 1/2” ID hose fitting
can be drilled and tapped directly into PVC pipe eliminates Tees and bushings for simpler installation

$2.75

$2.25

TAP1/4NPT



Threading tap (HSS) for installing above valve PBV1/2X1/4NPT - use 7/16 drill bit

$9.95

NA

PBV1/2X1/2

same as above no thread

1/2” Inline Valve
barb x barb
use with RCG13 grommet for push in pipe or vessel installation

CLICK



PBV012X012N

PBV012X012N-100p

1/2” barb x 1/2” Male NPT thread
use PVC or plastic bushing to adapt to your pipe thread size

$2.03

$1.89

PBV0916X012N

PBV012X012N-100p

9/16” (15mm) barb x 1/2” Male NPT thread
use PVC or plastic bushing to adapt to your pipe thread size

$2.10



PBV058X012N

PBV058X012N-100p

5/8” (16mm) barb x 1/2” Male NPT thread
use PVC or plastic bushing to adapt to your pipe thread size

$2.14



FV3/4

3/4”NPT Fill Valve

$2.50

$2.23

Custom Flo Fill Kit:
Unique complete components to design and build almost any combination of water return and filter intake for single aquariums or custom sump or refugiams. Venturi generators and various flow controls with multiple elbows, tube adapters, and directional jets to allow many flow possibilities.

Item #



Description

Price

3-6

PACFK

CustomFloCompleteKit

CustomFlo Kit
includes hose barb fittings for 1/2" and 3/4" hose

$45.00

CALL

PACF-SK

CustomFloSK

Custom-Flo Starter Kit
fits 5/8" ID hose
includes 2 over the top fittings with suction cups & hose barbs, 2 flow control valves , 1 suction intake screen, 1 coupling bracket with suction cup, 1 elbow bracket w suction cup, 2 pipe elbowsbarb x slip, 2 end caps thd, 1 pipe cap slip w/ suction cup, 1 spray bar, short 7/16" ID flex tubing, 1 ball socket flex 1/2.

$15.99

CALL

FlexibleBallSocket-multipleFlexible Ball/Socket Fittings - Black color
Useful on pump returns - can be threaded directly into threaded bulkhead fittings or PVC threaded fittings for directional control of flow. Also can be threaded onto submersible pump outlets for direct submersed applications.

1/2” sized tubing and fittings

FBSK-1/2



Ball socket joint tubing,
5 1/2” length

$3.35

FBSK-1/2NPT



1/2” Ball Socket male thd adptr
adapts ball/socket tubing to 1/2 “ threaded NPT fitting

$1.19

FBSK-1/2RN



1/2 Ball/Socket Round Nozzle
fits on end of 1/2 ball socket joint tubing to direct flow

$1.19

FBSK-1/2FN



1/2” Ball/Socket Flare Nozzle
fits on end of 1/2 ball/sockert tubing

$2.99

FBSK-1/2LN



1/2” Ball/Socket 90 deg Nozzle
fits on end of 1/2 ball socket tubing

$1.55

FBSK-1/2FC



1/2” Ball/Socket Female Connector
female socket x female socket

$2.56

FBSK-1/2FV



1/2” Ball/Socket Valve
female 1/2” NPT x ball/socket

$5.95

FBSK-1/2MV



1/2” Ball/Socket Valve
male 1/2” NPT x ball/socket

$5.95

FBSK-1/2IV



1/2” Ball/Socket in-line Valve
ball/socket x ball/socket

$5.95

FBSK-1/2Y



1/2” Ball/Socket Wye fitting
splits 1/2” ball/socket tubing 2 outlets

$2.69

FBSK-1/2AP



1/2” Ball/Socket Assembly Plier
eases assembly of joint tubing, adapters and nozzles

$11.95

3/4” Ball Socket Tubing and fittings

FBSK-3/4



Ball/Socket Joint Tubing 6” length

$4.29

FBSK-3/4MNPT



Ball/Socket Male Thd Adapter
adapts ball/socket tubing to 3/4 “ threaded NPT fitting

$1.40

FBSK-3/4RN



3/4” Ball/Socket Round Nozzle
fits on end of 3/4” ball socket joint tubing to direct flow

$1.40

FBSK-3/4FN



3/4” Ball/Socket Flare Nozzle
fits on end of 3/4 ball/sockert tubing

$4.09

FBSK-3/4Y



3/4” Ball/Socket Wye fitting
splits 3/4” ball/socket tubing 2 outlets

$4.09

FBSK-3/4-1/2



3/4” - 1/2 “Ball/Socket reducer
reduces 3/4” to 1/2” ball/socket

$2.89

FBSK-3/4FC



3/4” Ball/Socket Female Connector
female socket x female socket

$2.00

FBSK-3/4IV



3/4” Ball/Socket In-line Valve
female ball/socket x female ball/socket

$9.13

FBSK-3/4FV



3/4” Ball/Socket Female Valve
female 3/4 NPT x female 3/4 NPT

$9.13

FBSK-3/4MV



3/4” Ball/Socket Male Valve
male 3/4 NPT x male 3/4 NPT

$9.13

FBSK-3/4AP



3/4” Ball/Socket Assembly Plier
eases assembly of joint tubing, adapters and nozzles

$21.12

[JEHMCO Main] [ABOUT JEHMCO] [PRODUCTS:] [SPECIALS] [ORDERING INFO] [WHAT'S NEW] [SITE MAP]

CALL TOLL FREE: 1-800-521-6258
for Sales or Product questions, contact us at sales@jehmco.com
© Copyright 2010 JEHM Co., Inc.  All rights reserved
